Description

Teradek Serv Micro
Product Highlights:
  • Wirelessly Stream Video up to 10 Devices
  • Stream via Wi-Fi to Android/iOS VUER App
  • Up to 1080p Resolution via HDMI
  • Ethernet Connector, Records to SD Card
  • Simultaneous Bonding over 7 Networks
  • AES-256 Encryption, AVC Compression
  • Share Live Feeds via Teradek Core
  • Can Stream Locally without Internet
  • 3.5mm Mic/Line Audio Input
  • Teradek Serv Micro
  • Mini-HDMI Type C to HDMI Type A (18")
  • Ethernet Cable
  • 18W Power Adapter
  • Shoe Mount Adapter
  • 2 x Antenna
  • Limited 1-Year Warranty
Teradek Serv Micro
Teradek 10-0744 Serv Micro

Wirelessly stream up to 1080p30 video to 10 devices via Wi-Fi using the compact Serv Micro from Teradek. Like others in the Serv video transmitter line, the Serv Micro is ideal for sharing your footage on set from production to post. This allows your videographers, editors, and producers to work in close collaboration.

The Serv Micro inputs video via HDMI, inputs audio via 3.5mm mic/line input, and streams video via Wi-Fi, Ethernet, or via a separately available USB cellular modem. It is also capable of recording the monitored stream to an SD card. A free iOS and Android compatible app allows for local sharing and messaging using the Teradek VUER app, and doesn't require an internet connection. The Serv Micro is equipped with Teradek Core compatibility for sharing globally using various devices. It also supports 256-bit encryption to ensure secure sharing. It also supports bonding on up to 7 networks, via Ethernet, Wi-Fi, and cellular.

On-Set Streaming

  • Connect the crew from anywhere on set with live camera feeds streamed to 10 devices or 20 when connected to a local network via the free VUER app
  • Easy, customizable app monitoring tools
  • True image fidelity with critical resolution and color-accuracy with low delay
  • Distribute secure, 256-bit encrypted streams
  • Display up to four camera feeds at once

Off-Set Streaming

  • Share live camera feeds up to 1080p30 with remote stakeholders via the cloud to computers, TVs, smartphones, or tablets via Core
  • Collaborate live via integrated messaging and voice chat

Postproduction Streaming

  • Send up to 1080p30 video in real time to editors, colorists, VFX teams, directors, and other remote collaborators with Core
  • Send streams through the cloud to anymore in your production

Bonding

Simultaneous bonding over up to 7 networks:
  • Ethernet
  • Wi-Fi
  • USB cellular modem
  • Up to 4 smartphones (iOS or Android)
Teradek Serv Micro Specs
Inputs / Outputs
Antenna Ports 2 x RP-SMA
Video 1 x HDMI Type A (HDMI 2.0) Input
HDCP Support Not Specified by Manufacturer
Embedded Audio Not Specified by Manufacturer
Audio 1 x 1/8" / 3.5 mm Mic/Line Input
Power I/O 1 x Barrel Input
Other I/O 1 x USB Type-A 2.0 Input/Output
1 x RJ45 (10/100 Mb/s Ethernet) Input/Output
Media/Memory Card Slot Single Slot: SD/SDHC
Wireless
# of Channels 10
Wi-Fi Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz)
Format Support
Video Format HDMI (8-Bit 4:2:0)
1080p: 30
Timecode Support No
Power
DC Input Power 28 VDC
Battery Type 1 x L-Series
Power Consumption 6 W
Mounting
Mounting Not Specified by Manufacturer
Environmental
IP Rating None
General
Dimensions 4.1 x 3 x 1.1" / 105 x 75 x 28 mm
Weight 6.7 oz / 190 g / 0.42 lbs
