BirdDog Eyes P200 1080p Full NDI PTZ Camera (Black)
SEE PROMO AVAILABLE!
Product Highlights:
- For Indoor Stadiums / Large Spaces
- Fast 30x Optical Zoom and Autofocus
- Suitable for Fast-Action Sporting Events
- Custom NDI Silicon Chip (140 Mb/s)
- BirdDog Eyes P200 1080p Full NDI PTZ Camera (Black)
- Power Adapter
- Power Cord
- IR Remote Controller (Required CR2032 Coin Battery Not Included)
- Bag of Mounting Screws
- RJ45 to RS-232 Extension Cable
- RJ45 to RS-422 Extension Cable
- Limited 1-Year Warranty
BirdDog Eyes P200 1080p Full NDI PTZ Camera (White)
BirdDog BDP200W Eyes P200 1080p Full NDI PTZ Camera (Black)
Combining BirdDog's custom NDI silicon chip, 30x optical zoom, and Sony backlit sensor and image module, the BirdDog Eyes P200, in Black, is a full NDI 1080p60 PTZ camera designed for large indoor spaces. Thanks to the fast autofocus and zoom ensured by the true Sony image module, the P200 is highly suitable for catching all the fast action in places such as sporting events. As opposed to other types of NDI, such as NDI|HX, which is a compressed variant that reaches 12 Mb/s, the P200 features the visually lossless full NDI variable bit-rate iFrame codec that reaches up to 140 Mb/s at 1080p60.
Simultaneous, live SDI, HDMI, and full NDI outputs complete the camera as a comprehensive solution. Between these connections, you can control the P200 live via your full NDI workflow or integrate RS-422, RS-485, and RS-232 serial control. Also, the optional BirdDog PTZ Keyboard can be used over NDI or over RS-422/RS-232 in SDI mode. The P200 can be powered by Power-over-Ethernet (PoE) or via the included power adapter.
The Eyes P200 also comes with the BirdDog Comms Lite audio intercom software, which supports up to four BirdDog devices. Comms Lite is Windows-compatible and offers features such as director push to talk, mute camera operator, auto-detect NDI sources, monitor camera audio, and shortcut to Web console. For a more complete version of the application, an optional upgrade is available to Comms Pro. The camera is also compatible with the optional BirdDog Central software, which helps you decode NDI back to HDMI or SDI.
BirdDog EYES P200 Specs |
Image Sensor |
Image Sensor |
1-Chip 1/2.8" CMOS Sensor |
Sensor Resolution |
2.13 MP |
Minimum Illumination |
0.01 Lux at 1/30 Shutter Speed |
Camera |
Shutter Speed |
1/1 to 1/10,000 sec |
Max Digital Zoom |
12x |
Flip / Mirror Support |
Image Flip, Mirror (Vertical) |
Lens |
Optical Zoom Ratio |
30x |
Focal Length |
4.3 to 129mm |
Field of View |
Horizontal: 2.3 to 63.7° |
Maximum Aperture |
f/1.6 to 4.7 |
Focus Control |
Autofocus Manual Focus |
Video Output |
Output Formats |
SDI, HDMI, RJ45: 1920 x 1080p at 25, 29.97, 50, 59.94, 60 fps 1920 x 1080i at 50, 59.94, 60 fps 1280 x 720p at 25, 29.97, 50, 59.94, 60 fps |
Control |
Presets |
128 |
Move Speed |
150°/sec |
Movement Range |
Pan: 350° Tilt: -30 to 90° |
Supported Control Protocols |
Pelco-D VISCA |
Interfaces |
Video Output Connectors |
1 x RJ45 (NDI) 1 x BNC (3G-SDI) 1 x HDMI Type A (HDMI 1.4) |
Audio I/O |
1 x 1/8" / 3.5 mm Stereo Input 1 x 1/8" / 3.5 mm Stereo Output |
Control Interface |
1 x RJ45 (IP Control) |
Other I/O |
2 x RJ45 (RS-232, RS-422, RS-485) 1 x USB (Unspecified Type) |
Power |
PoE Support |
PoE+ 802.3at |
Power Connectors |
1 x Barrel / Coaxial (12 VDC) |
Environmental |
Operating Temperature |
14 to 122°F / -10 to 50°C |
Operating Humidity |
80% |
General |
Tripod Mounting Thread |
1 x 1/4"-20 Female |
Dimensions |
6.3 x 7.01 x 8.66" / 16 x 17.8 x 22 cm |
Weight |
4.41 lb / 2 kg |
Packaging Info |
Package Weight |
7.175 lb |
Box Dimensions (LxWxH) |
12.3 x 12 x 9.9" |
